| Brand Name: | Imhoo |
| Model Number: | 472 |
| MOQ: | 200 pieces |
| Price: | $4.99-6.50 / piece |
| Measurement Function | Ranges | Accuracy |
|---|---|---|
| Capacitance Test | 100pF~0.025uF/2.5uF/25uF .2000uF | ±3.0F.S. |
| DC Voltage | 100m/500m/2.5/10/50/250/1000v(20kΩ/V) 25kV(with Hvprobe) |
±3.0F.S. |
| AC Voltage | 10/50/250/1000v(9kΩ/V) | ±4%f.s. |
| DC Current | 50μ/2.5m/25m/250mA 2.5A,10A |
±3%f.s ±5%f.s |
| Resistance | 2/20k/200k/2M/20mΩ | ±3% of arc. |
| NULL | ±5V/±25V | ±5%f.s. |
| dB | -10-62dB | - |
| Ll | 150μ/1.5m/15m/150mA | - |
| hFE | 0-1000(w/TR connector) | - |
| Battery test | 1.5V | - |
| Power Supply | R6(1.5V)X2,6F22(9V)X1 | - |
| Dimension | 150×100×36mm | - |
| Weight | 280g | - |
| Parameter | Specification |
|---|---|
| Packing Type | Gift box (customizable) |
| Carton Size | 54×32×30cm |
| Standard Packing per Carton | 40pcs |
| Net Weight | 14kg |
| Gross Weight | 15kg |
