AC DC Analogic Meter Ohm VOLT Voltmeter Ohmmeter Ammeter Handheld Tester

Name: AC DC Analogic Meter Ohm VOLT Voltmeter Ohmmeter Ammeter Handheld Tester
Brand: Wuxi Imhoo Technology Co., Ltd.
SKU: HD-390C
Price: 7.70 USD
Availability: InStock

Brand Name:	imhoo
Model Number:	HD-390C
MOQ:	1 piece
Price:	$7.70-9.30 / piece

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu, China

Accuracy Class:

±(0.01% + 1)

Measuring Current Range:

0.1-250mA

Measuring Voltage Range:

0.25-1000v

Parameters Measured:

DC Current, AC Voltage

Dimensions:

160*105*40mm

Measuring Capacitance Range:

Measuring Inductance Range:

Measuring Resistance Range:

0.1Ω-20MΩ

Operating Temperature:

0-40℃

Color:

Red,blue

Transistor Test:

Yes

Continuity Buzzer Test:

Yes

Decibel Test:

Yes

Highlight:

AC volt voltmeter

DC volt voltmeter

250mA handheld tester

Product Description

Brand New Analog Multimeter

Professional analog multimeter for AC/DC voltage, resistance, and current measurements with comprehensive testing capabilities.

Key Features

22 test ranges with 8 working functions
Heavy ABS plastic housing with compact protective holster
Adjustable back tilt stand with hook-up design
High input impedance: 10KΩ/V DCV and 4.5 KΩ/V ACV
Good overload protection with fast-acting fuse 0.5A/250V
Continuity buzzer testing
Transistor hFE check via front jack
Decibel test capability (-20~+62dB)

Technical Specifications

DC Voltage Range (±3.0% F.S.): 0.25/2.5/10/50/250/1000V
AC Voltage Range (±4.0% F.S.): 10/50/250/1000V
DC Current Range (±3.0% F.S.): 0.1/2.5/25/250mA, 10A (±4.0% F.S.) without 10A fuse
Resistance Range (0.1Ω~20MΩ, ±3.0% of Arc.): x1, x10, x100, x1K, x10K
Dry Battery Check: 1.5V, 9V
Dimensions: 160×105×40mm
Weight: 320g approximately
Power Supply: 6F22 Dry Battery 9V 1pc and AA size 1.5V battery 1pc

Packaging Information

Packing Type	White Box
Carton Size	53×38×32cm
Standard Packing per Carton	32 pieces
Net Weight	18kg
Gross Weight	19kg
