240° Wide Angle IP42 Rated 0-800A AC Ammeter Panel Meter for Marine & Power Stations

Brand Name:	ymiho
Model Number:	TP-100IR

Detail Information

Product Description

Detail Information

Highlight:

240° Wide Angle Panel Meter

IP42 Rated AC Ammeter

0-800A Measurement Analog Ammeter

Product Description

0-800A AC Ammeter Panel Meter – 240° Wide Angle, IP42 Rated

Our wide-angle analog AC ammeter delivers 0-800A measurement with CT 800/5A, 240° dial clarity, and IP42 protection. Ideal for marine switchboards, power stations, and industrial control systems. High accuracy, easy panel mount, and reliable performance in harsh environments.

Product Overview

This high-performance analog AC ammeter is engineered for precision current monitoring in marine, power station, and industrial environments. With a 240° wide-angle dial and high-contrast pointer, it provides clear, intuitive readings of AC current from 0 to 800 amperes, paired with a CT ratio of 800/5A for accurate measurement in high-current systems.

Key Features

Wide-Angle Dial: 240° scale for enhanced readability and reduced eye strain
Rugged Construction: Metal casing with IP42 ingress protection, resistant to vibration, salt spray, and oil mist
High Accuracy: Class 1.5 precision for reliable current measurement in critical applications
CT Compatibility: Designed for use with CT 800/5A, ideal for high-current power systems
Easy Installation: Standard panel mount design with 101*101mm cutout, compatible with marine switchboards and industrial control panels
Marine & Industrial Grade: Designed to operate in temperatures from -25℃ to +55℃, ideal for shipboard use, power stations, and mobile power systems

Applications

Marine main switchboards and emergency power systems
Industrial power control and distribution panels
Mobile power stations and generator sets
Petrochemical and offshore drilling operations

Technical Specifications

Product Name	Wide-Angle Analog AC Ammeter
Measurement Range	0-800A AC
CT Ratio	800/5A
Accuracy Class	Class 1.5
Frequency	50/60Hz
Dial Angle	240° Wide Angle
Protection Grade	IP42
Operating Temperature	-25℃ ~ +55℃
Housing Material	Metal Casing with Transparent Cover
Mounting Type	Panel Mount
Panel Cutout Size	101 * 101 mm
Overall Panel Size	110 * 110 mm
Applications	Marine Switchboards, Power Stations, Industrial Control Systems
