| Brand Name: | imhoo |
| Model Number: | TP-100IR |
| MOQ: | 1 piece |
| Price: | $105-120 / piece |
| Full scale deflection angle | 250° (360° for synchroscope) |
| Full scale length | Approx. 196mm (7.7") for 110mm SQ 140mm (5.5") for 80mm SQ |
| Position of use | Vertical |
| Pointer | Lance type pointer, black |
| Operating temperature range | 0~40°C |
| Operating humidity range | 30~75% RH |
| Storage temperature range | -10~50°C |
| Storage humidity range | 25~80% RH |
| Dielectric strength | 2600V AC for one minute between electric circuit and the case 2000V AC for 2181A, 2182A, 2187A, 2188A |
| Insulation resistance | More than 10MΩ/500V DC between electrical circuit and the case More than 5MΩ/500V DC between electrical circuit and voltage circuit |
