| Brand Name: | IMHOO |
| Model Number: | IMH-130PDC |
| MOQ: | 500 pieces |
| Price: | $5-6 / piece |
| Type | Moving Coil |
| Accuracy | ±2% Full Scale |
| Tracking | ±1.5% Full Scale |
| Repeatability | ±0.5% Full Scale |
| Response Time | 1.5 Second Max for all ranges above 0-50 µA, which is 3.0 Sec Max |
| Symmetry | ±1.5% Full Scale |
| Resistance Tolerance | ±10% |
| Scale Arc | 100º |
| Shielding | Self Shielding |
| Item No | Ranges | Resistances | 1.5 | 2.5 | 3.5 | 4.5 |
|---|---|---|---|---|---|---|
| DC Microammeters | ||||||
| 1 | 0-20 | 6000 | IMH-110PDC | IMH-210PDC | IMH-310PDC | IMH-410PDC |
| 2 | 0-50 | 4000 | IMH-120PDC | IMH-220PDC | IMH-320PDC | IMH-420PDC |
| 3 | 0-100 | 3000 | IMH-130PDC | IMH-230PDC | IMH-330PDC | IMH-430PDC |
| 4 | 0-200 | 2000 | IMH-140PDC | IMH-240PDC | IMH-340PDC | IMH-440PDC |
| 5 | 0-500 | 1000 | IMH-150PDC | IMH-250PDC | IMH-350PDC | IMH-450PDC |
| 6 | 25-0-25 | 4000 | IMH-160PDC | IMH-260PDC | IMH-360PDC | IMH-460PDC |
| 7 | 50-0-50 | 3000 | IMH-170PDC | IMH-270PDC | IMH-370PDC | IMH-470PDC |
| 8 | 100-0-100 | 2000 | IMH-180PDC | IMH-280PDC | IMH-380PDC | IMH-480PDC |
| 9 | 500-0-500 | 150 | IMH-190PDC | IMH-290PDC | IMH-390PDC | IMH-490PDC |
| DC Milliammeters | ||||||
| 10 | 0-1 | 150 | IMH-1100PDC | IMH-2100PDC | IMH-3100PDC | IMH-4100PDC |
| 11 | 0-5 | 10 | IMH-1110PDC | IMH-2110PDC | IMH-3110PDC | IMH-4110PDC |
| 12 | 0-10 | 5 | IMH-1120PDC | IMH-2120PDC | IMH-3120PDC | IMH-4120PDC |
| 13 | 0-25 | 2 | IMH-1130PDC | IMH-2130PDC | IMH-3130PDC | IMH-4130PDC |
| 14 | 0-50 | 1 | IMH-1140PDC | IMH-2140PDC | IMH-3140PDC | IMH-4140PDC |
| 15 | 0-100 | 0.5 | IMH-1150PDC | IMH-2150PDC | IMH-3150PDC | IMH-4150PDC |
| 16 | 0-150 | 0.4 | IMH-1160PDC | IMH-2160PDC | IMH-3160PDC | IMH-4160PDC |
| 17 | 0-200 | 0.3 | IMH-1170PDC | IMH-2170PDC | IMH-3170PDC | IMH-4170PDC |
| 18 | 0-300 | 0.2 | IMH-1180PDC | IMH-2180PDC | IMH-3180PDC | IMH-4180PDC |
| 19 | 0-500 | 0.1 | IMH-1190PDC | IMH-2190PDC | IMH-3190PDC | IMH-4190PDC |
| DC Ammeters | ||||||
| 21 | 0-1 | 0.05 | IMH-1200PDC | IMH-2200PDC | IMH-3200PDC | IMH-4200PDC |
| 22 | 0-3 | 0.0166 | IMH-1210PDC | IMH-2210PDC | IMH-3210PDC | IMH-4210PDC |
| 23 | 0-5 | 0.01 | IMH-1220PDC | IMH-2220PDC | IMH-3220PDC | IMH-4220PDC |
| 24 | 0-10 | 0.005 | IMH-1230PDC | IMH-2230PDC | IMH-3230PDC | IMH-4230PDC |
| 25 | 0-15 | 0.0033 | IMH-1240PDC | IMH-2240PDC | IMH-3240PDC | IMH-4240PDC |
| 26 | 0-25 | 0.002 | IMH-1250PDC | IMH-2250PDC | IMH-3250PDC | IMH-4250PDC |
| 27 | 0-30 | 0.0017 | IMH-1260PDC | IMH-2260PDC | IMH-3260PDC | IMH-4260PDC |
| 28 | 0-50 | 0.001 | IMH-1270PDC | IMH-2270PDC | IMH-3270PDC | IMH-4270PDC |
