| Brand Name: | Imhoo |
| Model Number: | TP-45 DC A |
| MOQ: | 5 pieces |
| Price: | $3.20-4.60 / piece |
| Type | AC A Ranges | DC A Ranges |
|---|---|---|
| μA | 50μA, 100μA, 150μA, 500μA | 50μA, 100μA, 150μA, 500μA |
| mA | 1mA, 2mA, 5mA, 10mA, 20mA, 30mA, 50mA, 75mA, 100mA, 150mA, 200mA, 250mA, 300mA, 500mA | 1mA, 2mA, 5mA, 10mA, 20mA, 30mA, 50mA, 75mA, 100mA, 150mA, 200mA, 250mA, 300mA, 500mA |
| A | 1A, 2A, 3A, 7.5A, 10A, 20A, 30A, 50A | 1A, 2A, 3A, 7.5A, 10A, 20A, 30A, 50A |
| With External CT (ACA) | X1A: 10/1A, 15/1A, 20/1A, 30/1A, 40/1A, 50/1A, 60/1A, 75/1A, 100/1A, 150/1A, 200/1A, 300/1A, 400/1A, 500/1A, 600/1A, 1000/1A X5A: 10/5A, 15/5A, 20/5A, 30/5A, 40/5A, 50/5A, 60/5A, 75/5A, 100/5A, 150/5A, 200/5A, 300/5A, 400/5A, 500/5A, 600/5A, 1000/5A |
50mV, 60mV, 75mV: 10A, 15A, 20A, 30A, 40A, 50A, 60A, 100A, 150A, 200A, 250A, 300A, 400A, 500A, 600A, 800A, 1000A, 1500A, 2000A, 2500A, 3000A |
| Type | AC V Ranges | DC V Ranges |
|---|---|---|
| V | 50mV, 60mV, 75mV, 100mV, 5V, 10V, 15V, 20V, 30V, 50V, 75V, 100V, 120V, 150V, 200V, 250V, 300V, 400V, 450V, 500V, 600V | 50mV, 60mV, 75mV, 100mV, 5V, 10V, 15V, 20V, 30V, 50V, 75V, 100V, 120V, 150V, 200V, 250V, 300V, 400V, 450V, 500V, 600V |
| Model | Case Dimension | Panel Cutout Dimension |
|---|---|---|
| TP-45 | A: 45.2, B: 45.2, C: 8.5, D: 24, E: 9.8, F: ø38, M: 17, N: 9, O: ø3 | G: 31.3, H: 31.3 |
| TP-50 | A: 51, B: 51, C: 13, D: 22, E: 9.8, F: ø45.5, M: 19, N: 9, O: ø3 | G: 38, H: 38 |
| TP-60 | A: 60, B: 60, C: 14, D: 22.8, E: 10.8, F: ø51, M: 27, N: 12, O: ø3 | G: 48, H: 48 |
| TP-80 | A: 81.3, B: 81.3, C: 16, D: 22.8, E: 12.8, F: ø64, M: 35, N: 12, O: ø3 | G: 65, H: 65 |
